Kanaflex 180 AR – Product specifications

Applications

Heavy-duty abrasion resistant suction hose for vacuum trucks or handling abrasives, such as crushed rock, sand, pea gravel, cement powder, dry fertilizer, iron ore and grains. Contact Abdex for specific applications.

Features

• Lightweight and flexible.
• Extremely abrasion resistant.
• Static dissipating with no grounding wire.
• Smooth bore allows for precise flow, and promotes drainability.

	inch | mm	inch | mm	bar | psi	inch	kg/ft	Vacuum in/hg	Pitch inch	Length ft/mtr
KF180AR-032	1 1/4 | 32	1.6 | 41	3.10 | 45	2.0	0.14	29.8	0.33	100 / 30.48
KF180AR-040	1 1/2 | 38	1.9 | 48	3.10 | 45	2.0	0.17	29.8	0.35	100 / 30.48
KF180AR-050	2 | 51	2.4 | 61	2.76 | 45	2.5	0.22	29.8	0.39	100 / 30.48
KF180AR-065	2 1/2 | 64	3.0 | 76	2.41 | 35	2.5	0.39	29.8	0.56	98.5 / 30
KF180AR-080	3 | 76	3.5 | 89	2.41 | 35	3.0	0.50	29.8	0.59	98.5 / 30
KF180AR-090	3 1/2 | 89	4.11 | 104	2.07 | 30	4.0	0.61	29.8	0.64	100 / 30.48
KF180AR-100	4 | 102	4.63 | 118	2.07 | 30	4.5	0.80	29.8	0.65	100 / 30.48
KF180AR-125	5 | 127	5.76 | 146	2.07 | 30	5.0	1.12	28.0	0.87	100 / 30.48
KF180AR-150	6 | 152	6.8 | 173	2.07 | 30	9.2	1.39	28.0	0.87	100 / 30.48
KF180AR-180	7 | 178	7.83 | 199	2.07 | 30	14.0	1.86	27.0	0.87	100 / 30.48
KF180AR-200	8 | 203	9.04 | 230	2.07 | 30	15.0	2.56	27.0	0.91	100 / 30.48
KF180AR-250	10 | 254	11.18 | 284	1.93 | 28	30.0	4,03	25.0	1.00	100 / 30.48
KF180AR-300	12 | 305	13.31 | 338	1.72 | 25	40.0	4.73	25.0	1.18	100 / 30.48

Construction

Core tube: SBR rubber blended with static carbon black.
Pressure reinforcement: Rigid PVC helix, smooth bore, corrugated O.D.
Cover: Carbon black.

Temperature Range

-40 ̊C to 60 ̊C.-40 ̊F to 140 ̊F.
