Hose Coiling Machine – AB-MCCV-1000

Hose Coiling Machine – AB-MCCV-1000

Hose Coiling, Measuring & Cutting



Features and Benefits

• Semi auto coiling, measuring and cutting station
• Fast clamping system for hose coiler
• Foot switch with speed control for precise coiling
• High quality coiling motor with electronic brake wheel cut out for safe working

Description

AB-MCCV-1000 – Technical Data
AB-MCCV-1000
Production SAE R13 and SAE R153/4"
Workshop SAE R13 and SAE R153/4"
4SP3/4"
Industrial3/4"
Max outside diameter40mm
Noise level80 dBA
Brake motor3 Seconds
Suction connection50mm
Drive2 kW
Cutting blade (mm)210 x 2.5 x 30
UVC AdaptorFL-50-AS18-AD
Max load capacity - Coiler120 kg
Max coil diameter - Coiler1000mm
Max hose size - Coiler3/4"
Speed0 - 36 rpm
Max hose size - Measuring device3/4"
Measuring counter - Measuring deviceManual reset
Length tolerance - Measuring device(+ - 2%)
L x W x H (mm)410 x 200 x 120
Weight115 kg
