Aflex Hyperline AU

Lightweight convoluted PTFE-lined hose for motorsport

Hyperline AU is a fully convoluted PTFE-lined hose developed specifically for the motorsport industry. It combines exceptional flexibility and high pressure rating with one of the lightest constructions available in a convoluted hose.

The fully convoluted design allows Hyperline AU to be used at a centreline bend radius of 1½ times the hose bore diameter, with excellent resistance to flex fatigue. This opens up new routing options for applications where tight bends or rapid flexing are required.

Category:

Description

Technical Data
SpecificationValue
Nominal bore size7.1 to 32 mm (1/4″ to 1 1/4″)
Outside diameter9.91 to 37.97 mm
Max. operating pressureUp to 70 bar (1025 psi)
Bend radius19 to 75 mm
Temperature rangeUp to 230°C (SS grades)
ConstructionTube only, SS braid, or aramid braid
LinerNatural or anti-static (ASTM D4895)

Features
  • Fully convoluted internally and externally for exceptional flexibility
  • Lightweight construction, one of the lightest convoluted hoses available
  • High pressure rating for a convoluted hose
  • Excellent flex fatigue resistance
  • Developed for motorsport applications
  • Available with natural or anti-static PTFE liner
  •
Datasheet Download

Hyperline AU Datasheet
