Description
Hose Cleaning Machine RG 2, RG 10 – Technical Data
| RG 2 | RH 10 | |
|---|---|---|
| Drive | Diaphragm pump, 7 bar air | Diaphragm pump, 7 bar air |
| Maximum flow rate | 25 l/min | 180 l/min |
| Pressure filter | 5 μm | 10 μm |
| Air filter | 5 μm | 5 μm |
| Max. air consumption | 100 Nl/min | 250 Nl/min |
| Working range | up to 1 1/4" ID | up to 2" ID |
| Max. length, depending on bore size | 2.5 m / 8 feet | 20 m / 65 feet |
| Tank capacity | 38 L | 215 L |
| Working area | 350 x 750 | 800 x 1,600 |
| Cleaning agent | Non-toxic and corrosion-free emulsion, water based | Non-toxic and corrosion-free emulsion, water based |
| L x W x H (mm) | 960 x 435 x 940 | 2,000 x 840 x 1050 |
| Weight (empty) | 55 kg | 160 kg |
