Description
| PART NUMBER | THREAD | HOSE INCH | HOSE DN (mm) | CH | A | B |
|---|---|---|---|---|---|---|
| 4T-4MBSPTSP | 1/4 – 19 | 1/4 | 6 | 15 | 27 | 14 |
| 4T-6MBSPTSP | 3/8 – 19 | 1/4 | 6 | 19 | 28.5 | 15 |
| 6T-6MBSPTSP | 3/8 – 19 | 3/8 | 10 | 19 | 29 | 14.5 |
| 6T-8MBSPTSP | 1/2 – 14 | 3/8 | 10 | 22 | 34.5 | 19 |
| 8T-8MBSPTSP | 1/2 – 14 | 1/2 | 12 | 22 | 35.1 | 19 |
| 12T-12MBSPTSP | 3/4 – 14 | 3/4 | 19 | 27 | 37.1 | 19 |
| 16T-16MBSPTSP | 1 – 11 | 1 | 25 | 36 | 44.1 | 24 |
