Description
NPTF MALE
| PART NUMBER | THREAD | HOSE INCH | HOSE DN (mm) | CH | CH1 | A |
|---|---|---|---|---|---|---|
| 4T-4MP | 1/4 - 19 | 1/4 | 6 | 15 | 27.1 | 14.2 |
| 6T-6MP | 3/8 - 19 | 3/8 | 10 | 19 | 28.7 | 14.2 |
| 8T-8MP | 1/2 - 14 | 1/2 | 12 | 22 | 35.1 | 19 |
| 12T-12MP | 3/4 - 14 | 3/4 | 19 | 27 | 37.1 | 19 |
| 16T-16MP | 1 - 11.5 | 1 | 25 | 36 | 44 | 23.9 |
NPTF Male
NPTF MALE
| PART NUMBER | THREAD | HOSE INCH | HOSE DN (mm) | CH | CH1 | A |
|---|---|---|---|---|---|---|
| 4T-4MP | 1/4 - 19 | 1/4 | 6 | 15 | 27.1 | 14.2 |
| 6T-6MP | 3/8 - 19 | 3/8 | 10 | 19 | 28.7 | 14.2 |
| 8T-8MP | 1/2 - 14 | 1/2 | 12 | 22 | 35.1 | 19 |
| 12T-12MP | 3/4 - 14 | 3/4 | 19 | 27 | 37.1 | 19 |
| 16T-16MP | 1 - 11.5 | 1 | 25 | 36 | 44 | 23.9 |
