Description
METRIC O-RING FEMALE 45° ELBOW, 24° CONE, LIGHT
| PART NUMBER | THREAD | HOSE INCH | HOSE DN (mm) | STANDPIPE (mm) | CH | A | P |
|---|---|---|---|---|---|---|---|
| 4T-6FDLORX45 | M12 X 1.5 | 1/4 | 6 | 6 | 14 | 47 | 22 |
| 4T-8FDLORX45 | M14 X 1.5 | 1/4 | 6 | 8 | 17 | 50 | 17 |
| 4T-10FDLORX45 | M16 x 1.5 | 1/4 | 6 | 10 | 19 | 52 | 18 |
| 4T-12FDLORX45 | M18 X 1.5 | 1/4 | 6 | 12 | 22 | 52 | 17 |
| 6T-12FDLORX45 | M18 X 1.5 | 3/8 | 10 | 12 | 22 | 58 | 18 |
| 6T-15FDLORX45 | M22 X 1.5 | 3/8 | 10 | 15 | 27 | 60 | 19 |
| 8T-15FDLORX45 | M22 X 1.5 | 1/2 | 12 | 15 | 27 | 65 | 21 |
| 8T-18FDLORX45 | M26 X 1.5 | 1/2 | 12 | 18 | 32 | 65 | 23 |
| 10T-18FDLORX45 | M26 X 1.5 | 5/8 | 16 | 18 | 32 | 74 | 23 |
| 12T-22FDLORX45 | M30 X 2 | 3/4 | 19 | 22 | 36 | 80 | 24 |
| 16T-28FDLORX45 | M36 X 2 | 1 | 25 | 28 | 41 | 109 | 30 |
